Adata ASP900NS34-256GM-C Datenblatt PDF herunterladen

Premier Pro SP900 M.2 SATA SSD

The Premier Pro SP900 M.2 2242 and 2280 SATA 6Gb/s SSDs are built for PC development of the next

generation – “faster and smaller”. The SP900 M.2 2242 and 2280 are even smaller than a 2.5” SSD and

mSATA, but come with 128/256/512GB in capacity. Both of the two models are suitable for ultrabooks and

motherboards. Thanks to the support of Intel® Smart Response Technology, the SP900 M.2 2242 and 2280

provide sequential read/write speeds up to 550/530 MB/s for excellent performance. With the support of

DVESLP (Device Sleep) technology, the SP900 M.2 2242/2280 consumes less power for longer battery life.

Features

Ordering Information

● Applicable to Intel® Smart Response Technology

Capacity

Model Number

EAN Code

● Support DVESLP with Low power consumption

128GB

ASP900NS34-128GM-C

4712366960213

● Consistent high transfer speed

256GB

ASP900NS34-256GM-C

4712366960220

● NCQ Support

128GB

ASP900NS38-128GM-C

4712366960237

● Supports Windows TRIM Command

256GB

ASP900NS38-256GM-C

4712366960244

● S.M.A.R.T supported

512GB

ASP900NS38-512GM-C

4712366960251

● Small form-factor and minimum weight

Specifications

● Capacities: 128GB/256GB/512GB

● Warranty: 3 years

● NAND Flash Memory: Synchronous MLC

● MTBF: 1,200,000 hours

● Interface: SATA 6Gb/sec (SATA III)

● Operating Temperature: 0~70°C

● Controller: LSI SF-2281

● Storage Temperature: -40~85°C

● Form Factor: M.2 2242/2280

● Shock Resistance: 1500G

● Dimensions: 100 x 70 x 7mm (L x W x H)

● Operating Humidity: 10% to 90% RH (0° to 40°C)

● Weight: 4g/ 8g

● Storing Humidity: 5% to 95% RH (-10° to 40°C)

1 2

Inhaltsverzeichnis

Seite 1 - Specifications

Premier Pro SP900 M.2 SATA SSD The Premier Pro SP900 M.2 2242 and 2280 SATA 6Gb/s SSDs are built for PC development of the next gene

Seite 2 - Dimensional Drawings

Performance Capacity Read Speed ATTO (MB/sec) Write Speed ATTO (MB/sec) Sequential Read AS SSD (MB/sec) Sequential Write AS SSD (MB/sec) 4K Rand
